Dcr-1 Tension Clamp Fitting Optical Cable Tension Clamp
Feature & Benefit
Simple installation and convenient maintenance
High mechanical, electrical load capacity
Well performance under extreme environment
Standards compliance with CE, UL, RoHS, DMT
Product Description
DCR-1 overhead line dead end clamp
Material：Nylon plus fiber glass
Product property：They plastic anchoring clamp is suitable for insulated low-voltage ABC cable .It is also suitable for multiple conductors
Easy installation and perfect insulated function .It is in accordance with the NFC 33-042 .
Technical specification
| Dimension | ||
| Weight: | 139g | |
| Cable Size: | 4-25 mm² | |
| Mechanical | ||
| Breaking Load | ||
| Specification | ||
| Use: | For dead-ending of cables with round shape. | |
| Construction | Component | Material |
| Body and Wedge | Weather and UV-radiation resistant thermoplastic | |
| Bail | Hot-dip galvanized steel | |
| Installation | The clamp is opened and the messenger wire is inserted between the wedge and the body. The clamp is then closed and strained. | |
| Standard | NFC 33-042; EN 50-483 | |
| Model | Coss-section (mm2) |
| STA | 1×10/1×16 |
| STB | 2×16/2×25 |
| STC | 4×16/4×25 |
| STD | 1×16/1×70 |
| LA1 | 4×16/4×25 |
| LA2 | 2×6/2×16 |
| DCR-1 | 1×4/1×25 |
| DCR-2 | 1×4/1×25 |
| 2.1 | 16-25 |
| PA1500 | 25-50 |
| PA2000 | 54.6-70 |
